Zip Zoom Settings
Zip Zoom Factory Settings
PIN 1
IRQ 11
I/O Port Address
140h-15Fh
The factory settings on the Zip zoom board should work with most operating
systems, including DOS/Windows, Windows 95, Windows NT, and OS/2.
However, you will need to change the settings if:
Another device on your system is using IRQ 11 or I/O Port Address 140h-
15Fh.
You have an Adaptec SCSI adapter, Jaz jet ISA, or PC1600 installed.
M NOTE: Zip zoom jumper settings must be changed manually.
Under Windows 95, you must run the Add New Hardware control
panel
after making any setting changes. M
Optional Zip Zoom Settings
Alternate Port Address Optional IRQ Interrupts
Jumper OFF
or Hanging = I/O
Port Address
340h-35Fh
*IRQ 11 must be
used with
Windows NT
IRQ 9
IRQ 10
IRQ 11*
IRQ 12
14
