ION CLASSIC LP - Features Overview

4
Features
1. Platter – Place your record here.
2. 45 RPM Adapter Holder –
Holds
the includ
ed 45 RPM adapter.
When not using the adapter, please
place it in this holder.
3. Tonearm – The tonearm can be
raised and lowered by hand, or
by
pressing th
e raise / lower lever.
4. Arm Clip – This specially designed
arm clip secures the tonearm while
at rest or when not in use. The arm
clip has been designed to remain in
the up position while unlocked.
5. Raise / Lower Lever –
Raises and
lowers the
tonearm.
6. 33 / 45 / 78 Switch* –
This switch
controls the RPM of the
turntable
platter.
Note: For best results when play-
ing 78 RPM vinyl re
cords, use a 78
stylus (sold separately). Only use a
78 stylus with
78 RPM vinyl records. Purchase the
iCT06rs 78 stylus at ionaudio.com/ict06rs.
7. Autostop switch – This switch turns autost
op on or off.
When autostop is
on, the platter will start spinning when
the tonearm is placed over the record and stop spinning
when the record has reached the end. (When autostop
is
off,
the platter will always spin regardless of the position
of the to
nearm.)
Note: If your
vinyl record stops before it reaches the
end of the music, turn Autostop to the off po
sition for
this particul
ar record. This is generally
recommended
for
45 RPM records.
8. RCA Output*
* – The audio from a playing vinyl record
is
sent to this line-level coaxial audio outpu
t. This must
not
be connected to phono level devices.
9. USB Audio Output – Use the included USB cable to
connect your turntable to your computer. The USB
connection will send audio from the turntable to your
computer. Please see the Using Classic LP Wi
th Your
Computer
section of this manual for information.
10. Power Cable Input – Use the included adapter to
connect to wall power.
11. Power Button – Press this button to turn CLASSIC LP
on/of
f.
IMPORTANT: Remove the plastic
cartridge cover (needle cover) before
o
p
eratin
g
the turntable.
**WARNING: The RCA outputs are LINE
level. Please only connect these to LINE
level inputs. You may damage your
receiver if you plug in a LINE level device
into a PHONO level in
p
ut.
*If needed, you may adjust the speed of
the
turntable platter. On the underside
of
CLASSIC LP
, remove the rubber pl
ugs
and tigh
ten/loosen the appropriate sc
rew
with a
screwdriver.
