iOptron HE692 - Identification of Parts; HAE Mount Port

7
2.2. Identification of Parts
Bubble Level/iPolar
Mounting Base
DEC Axis
AZI Adj. Screws
Dovetail Saddle
RA Axis/Polar Axis
ALT Adj. Knob
AZI Locking Screws
Figure 1. HAE mount assembly
2.3. HAE Mount Port
The HAE69 mount may come with one of the following layout:
(a)
(b)
Figure 2. Ports on an HAE mount
 DC 12V IN: DC power socket to power the mount (5.5mmX2.5mm/5525, center positive)
 I/O: Power switch
