Installation
The method described below may vary from the actual installation and is subjected to proper adjustment
depending on the circumstances, local building codes, or state regulations.
Wall mount using mounting template:
1. Make sure you have:
(1) Drilled the input cable hole and the mounting holes on your
charger. (For details, see Page 18 and 19.)
(2) The installation height at least 60cm (or as required by
local regulations considering areas that are subject to
snowfall) as shown on the right.
2. Use the mounting layout template provided to drill the holes.
(1) Tape the layout template on the wall to the position where
you plan to install the charger.
(2) Mark the mounting holes (which are marked as circles on the template) onto the wall.
(3) Remove the template.
