EV Charger Fact Sheet
Electrical
Max Output Current (Amperage) Up to 80A
Phase Single
AC Power Input Rating - Standard 208/240VAC 60Hz single phase
With IEC15118/ISO15118 YES
Certifications
UL2594, UL50E, UL2231, UL991,
FCC Part 15 Class B
Wiring – Standard 3-wire (L1, L2, G)
Output Power (kW @ max A) 19.2kW (240VAC @ 80A)
Input Cord Requirement Hardwire
Charging plug SAE J1772 (80A)
