Charging the vehicle

If authentication is required, there are two ways to initiate charging of the vehicle:

1. Authenticate before inserting the cable into the vehicle.

2. Insert the cable into the vehicle and then authenticate.

Authentication prior to connecting the charging cable

1. To authenticate the use of the charger, hold or touch the RFID card over the LED until the LED

shows rotating white.

a. If the authentication fails, the LED shows steady orange. Retry authentication.

b. When the authentication is successful, the LED shows pulsing white.

2. Connect the cable to the vehicle following the instructions provided by the vehicle manufacturer.

a. While the charger prepares to charge, the LED may show blinking white.

b. Once charging begins, the LED shows pulsing green. When charging is complete, the LED

changes to steady green.
