IPC CT46 - CT46 TECHNICAL SPECIFICATIONS

GB
CT46 TECHNICAL SPECIFICATIONS
CT46 B50 CT46 C50
Cleaning width mm 500
Squeegee width mm 730
Cleaning capacity per hour m
2
/h 1750
Number of brushes n° 1
Brush diameter mm 500
Maximum brush pressure g/cm
2
16-20
Brush rotation speed g/1° 155 140
Brush motor power W 360 450
Drive motor power W /
Maximum speed Km/h 3,5
Suction motor power W 550 400
Solution tank L 40
Dirty water tank L 45
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 188 / 104
Transported weight Kg 128 / 40
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 105 /
Power system voltage V 24 220-240
Power supply frequency Hz / / 50 - 60
Rated power W 910 / 850
Rated current A 38 / 3,8
Machine dimensions mm
X=1065
Z=1280
Z1=950
Y=715
Battery compartment dimensions
(length, width, height)
mm 340x355x305 /
Packed size (length, width, height) mm 1270x680x1130
Sound pressure (EN 60704)
LpA
(dBA)
70 / 73
11
