IPC CT46 - CT45 TECHNICAL SPECIFICATIONS

GB
CT45 TECHNICAL SPECIFICATIONS
CT45 B50
CT45 BT50
CT45 C50
Cleaning width mm 500
Squeegee width mm 730
Cleaning capacity per hour m
2
/h 1750
Number of brushes n° 1
Brush diameter mm 500
Maximum brush pressure g/cm
2
/
Brush rotation speed g/1° 160 140
Brush motor power W 400 450
Drive motor power W 180
Maximum speed Km/h 3,5
Suction motor power W 550 400
Solution tank L 40
Dirty water tank L 45
Rear wheel diameter mm 250
Maximum slope % 2
Gross weight Kg 140 145 105
Transported weight Kg 88 88 40
Number of batteries n° 2
Battery voltage V 12
Individual battery capacity Ah (5h) 74 /
Power system voltage V 100-240
115
220
Machine dimensions mm
X=980
Z=1290
Z1=806
Y=715
Battery compartment dimensions
(length, width, height)
mm 265x335x255 /
Packed size (length, width, height) mm
Sound pressure (EN 60704)
LpA
(dBA)
72 72 72
Measurement uncertainty
K
(dBA)
2,5 2,5 2,5
Vibration level (hand) (IEC 60335-2-72)
ahv
m/sec
2
≤2,5 ≤2,5 ≤2,5
9
