iPECS LIK-MFIM50A - LIK-MFIM50 B Installation

- LIK50 Description & Installation
Issue 1.2.1
35
4.4.2 LIK-MFIM50B Installation
LIK-MFIM50B can be installed anywhere in 1U Data Rack Holder, Desk Mount Holder or Wall
Mount Holder.
LIK-MFIM50B contains a long life Lithium battery, which protects the memory and real-time clock
in the event of a power failure. Minimum battery life is 10 years and the battery is not field-
replaceable.
LEDs
In addition to the Power and LAN LEDs, LIK-MFIM50B has ten LEDs for status and diagnostic
information as in Table 4.4.2-1.
Table 4.4.2-1 MFIM50B Status LED Functions
LED DESIGNATION
LED STATUS FUNCTION - ON -
S1
Serial/TCP debug active
S2
Call Processing active
S3
Active data communication with Modules and IP Phones
S4
CPU active (100ms flashing)
VSF
VSF Active (Flashing)
BRI1
BRI Port 1 In-use
BRI2
BRI Port 2 In-use
BRI3
BRI Port 3 In-use
BRI4
BRI Port 4 In-use
VSF
FXS ports In-use
MODE Switch & Settings
MFIMs have a four (4) position DIP-switch identified as the “MODE” switch. The function of each
switch position is given in Table 4.4.2-2 below.
Table 4.4.2-2 MFIM50B MODE Switch Functions
Name
Contact
FUNCTION
ON
OFF
MODE
1
Database write protect
Protect
Unprotect
2
Boot mode protect
Enable
Disable
3
Registration
Allow registration
Deny Registration
4
initialization
Initialize DB on reset
Read Stored DB on reset
To enter data in the system’s database, the Write Protect switch must be in the OFF position. In
the ON position, the database cannot be modified. Thus, placing the switch in the ON position
eliminates the potential for remote database modification. If remote data entry is not desired, after
all installation and database entries are complete place the switch in the ON position.
When new gateway Modules and/or terminals are connected to a LAN, they will automatically
attempt to register with an LIK-MFIM50B. With the Registration switch (switch 3) in the ON
position, the system will recognize and respond to the registration request. With the switch in the
