SECTION III
Operation
Page 3.12
BP+2.9X
11/95
3.6 UPS Operating Procedures (continued)
3.6.1 System Startup Procedure (continued)
Normally, turning on the UPS CONTROL switch should illuminate the
following LED’s:
AC Input Failure Transfer Not Available
Retransfer Inhibited Battery Not Available
… and this screen which will be
displayed for a short time,
. . . . . then –
2. When this instruction appears on the
Message Screen, close BYPASS CIRCUIT
BREAKER. The same LED’s should remain
lighted. Power is available now on the UPS
output.
3. When this instruction appears on
the Message Screen, close the INPUT CIRCUIT
BREAKER.
Checksum
Good
Close
BYPASS
CKT. BREAKER
Close
INPUT
CKT. BREAKER
