IPM balancedpower plus - System Shutdown and Faults

SECTION III
Operation
Page 3.47
BP+2.9X
11/95
3.6 UPS Operating Procedures (continued)
3.6.3 UPS Maintenance Menu (continued)
3.6.3.5 Password Maintenance Menu (continued)
8. Press  to obtain this screen.
9. Press

to return to the Password
Maintenance Menu.
10. Depress  to return to Previous Menu.
11. Depress

to leave UPS Maintenance Menu.
3.6.4 System Shutdown
1. Perform the Bypass/Shutdown procedure (Paragraph 3.6.3.3).
NOTE: This leaves the critical load powered by the utility power source
through the bypass.
2. To remove all power to the load, open the BYPASS CIRCUIT BREAKER.
3.6.5.CPU Fault
If this message should appear on the
screen, the UPS is transferred to bypass. Call
Service Hotline at (800) 777-8922.
Return to
Previous
Menu
Password
Maintenance
Menu
