SECTION III
Operation
Page 3.26
BP+2.9X
11/95
3.6 UPS Operating Procedures (continued)
3.6.3 UPS Maintenance Menu (continued)
4. Now depress
to activate the second
digit. Press
or
until the “F” shows, like this:
5. Depress
to activate the third digit.
The screen will show:
6. Depress
again to activate the fourth
digit to obtain:
7. Depress
to bring up the first of the
secondary menus. Depress
to bring up the
other four Maintenance Menus in turn. Some-
times it will be faster to depress
to obtain the
desired menu.
3.6.3.1 Rectifier Maintenance Menu
To be used only when advised by
qualified service personnel
1. When in the Rectifier Maintenance
Menu, depress
.
When this screen is
displayed, press
to reset the faults.
Enter Password
4F
Enter Password
4F0
Enter Password
4F00
Rectifier
Maintenance
Menu
Reset Rect Faults
UP = Reset
To Next Page
