iPower AWP80 - Specifications

31
11.
Specifications
Tuneup
Spark plug gap
0.70 －0.80 mm
See page 22.
Idle speed
1800± 50 r pm
Valve clearance (cold)
Exhaust: 0.20 ± 0.02 m
m
Intake: 0.15 ± 0.02 m
m
Other specifications No other adjustments needed.
Model SUWP50 SUWP80 SUWP100
Dia.of discharge port 2＂(50mm)
2＂(50mm)
3＂(80mm)
3＂(80mm)
4＂(100mm)
4＂(100mm)Dia.of suction port
Lift 82 ft. (25m) 92 ft. (28m) 115 ft. (35m)
Delivery volum
（m³ /h)
30
（m³ /h)
60 （m³ /h)96
Suction 16.4＂(5m) 16.4＂(5m) 16.4＂(5m)
Engine model AP168FB AP170F AP188F
Displacement(cc) 196 208 389
Reted speed(rpm) 3600 3600 3600
Oil capactiy 0.16 gal. (0.6L)
0.95 gal. (3.6L) 0.95 gal. (3.6L) 1.72 gal. (6.5L)
0.16 gal. (0.6L) 0.29 gal. (1.1L)
Gasoline capactiy
Dimension
515X415X420 (mm)
20.3＂X16.3＂X16.5＂
515X415X420 (mm)
20.3＂X16.3＂X16.5＂
615X480X505 (mm)
24.2＂X18.9＂X19.9＂
Net weight 50.6 lb.(23kg) 55 lb.(25kg) 61.6 lb.(28kg)
