7
Wireless Footswitch and EMC
Setting Up the Wireless Footswitch
The wireless footswitch comprises:
• Battery-poweredfootswitch(withorwithoutpoweradjust)
• Laserconsole-poweredreceiver
Connect the wireless receiver to the footswitch receptacle on the rear of the laser. Three pedals
(as applicable) on the footswitch control the following:
• Leftpedal=decreasepower(holddowntoramptheparameter)
• Centerpedal=activatelaser
• Rightpedal=increasepower(holddowntoramptheparameter)
CAUTION: Each footswitch/receiver pair is uniquely linked and will not work with other IRIDEX
footswitches or similar components. Clearly identify each pair to prevent separation of
the linked components.
NOTE: The footswitch is designed to operate within 15 feet (5 meters) of the laser.
Testing the Batteries
NOTE: When batteries need to be replaced, contact your sales representative or IRIDEX Customer
Service. The wireless footswitch was designed with a battery life expectancy of 3 – 5 years of
normal operation and use.
LEDs on the footswitch assist in troubleshooting and indicate battery conditions as follows:
Footswitch LED Display Status
Green ash following pedal depression Footswitch OK
Batteries OK
Amber ash following pedal depression Footswitch OK
Batteries low
Blinking red LED for 10 seconds following pedal depression No RF communication
