Iridex IQ 577 - Using the Laser System

15510-EN Rev G Operation 17
Using the Laser System
System Interface
A Touchscreen
Interface
Displays current parameter and functions, and acts as the interface to select
screens or parameters.
B Control knobs Used to adjust parameters on the screen.
C Laser button Toggles between laser Ready and Standby modes.
A
C
B
