4
Troubleshooting
General Problems
Problem User Action(s)
No display • Verify that the keyswitch is on.
• Verify that the components are properly connected.
• Verify that the electrical service is on.
• Inspect the fuses.
If there is still no display, contact your local IRIDEX Technical Support
representative.
Inadequate or no aiming beam • Verify that the delivery device is properly connected.
• Verify that the console is in Treat mode.
• Turn the aiming beam control fully clockwise.
• Verify that the ber-optic connector is not damaged.
• If possible, connect another IRIDEX delivery device and place the
console in Treat mode.
If the aiming beam is still not visible, contact your local IRIDEX Technical
Support representative.
No treatment beam • Verify that the remote interlock has not been activated.
• Verify that the aiming beam is visible.
• Verify that the ber switch is in the correct position for the laser system
and wavelength you are using.
• Verify that the eye safety lter is in the closed position.
If there is still no treatment beam, contact your local IRIDEX Technical
Support representative.
No illumination light
(LIO only)
• Verify that the illumination connector is connected to the console.
• Verify that the special function control is not between detents.
• Check the bulb and replace it (if necessary).
Illumination light is too dim
(LIO only)
• Verify that the special function control is not between detents.
• Adjust the console illumination intensity control.
The aiming beam is large or out of
focus on the patients’ retina
(LIO only)
Readjust your working distance between the LIO headset and the
examination lens. The aiming beam should be sharply dened and at its
smallest diameter when in focus.
