Iridium GO! exec - SOS Button Configuration and Activation

Iridium GO! exec Single Mode Antenna LITE Kit (No GNSS)
11
Color White (non-glossy)
Height 150 mm (191.5 mm mounting base included)
Diameter Ø 95 mm
Mounting
Supplied Mounting or any US-style Mounting Bracket with 1"-14NF thread.
Mounting place On marine vessel or remote homes
Materials ASA, copper, PCB, stainless steel and brass
Operating temperature -40C to +70C
Connector 1 SAT: TNC-female
IP rating IP68
SAT Cable See 5m/16.404ft passive SAT antenna cable specifications
4.2 Mast/Rail Mount
Stainless Steel Mast/Rail Mounting Bracket
Mechanical Specifications:
Color Polished
Mounting
On pole or rail with supplied U-bolts
Mounting place On vertical or horizontal pole or rail with diameter Ø 30-60 mm
Materials Polished high grade AISI-316 stainless steel
For Antenna Types Supplied Iridium Marine antenna
Dimensions 130 x 92.5 x 40 mm
4.3 5m/17ft Passive SAT Antenna Cable
Electrical Specifications:
Impedance 50 Ω
Capacitance 78.41 pF/M (23.9 pF/ft)
Velocity of Propagation 84%
Voltage Withstand 2500 VDC
Max Operating Frequency 8 GHz
Physical Specifications:
Bending Radius Static 25.4mm (1”)
Bending Radius Repeated 103mm (4.0”)
Weight
0.10 kg/m or 0.068 lb/ft
Connectors TNC-M (Iridium GO! exec – cable adaptor)
TNC-M (Iridium Antenna – connector1)
Cable diameter
0.405” or 10.287mm
Connector Diameter
See TNC connector specs
