N°REV REVISION DESCRIPTION DATE REV. REVISER
00
FIRST EMISSION
01/12/2015
NC
U S E A N D
M A I N T E N A N C E
I N S T R U C T I O N S

Table of Contents

Questions and Answers

  • R
    rmunozAug 15, 2025
    How to troubleshoot the front board if it does not turn on in my Irinox Refrigerator?
    • M
      mfloresAug 15, 2025
      If the front board of your Irinox Refrigerator doesn't turn on, first check the electrical line connection to ensure there is a power supply. If the power supply is fine, inspect the Bus cable and ensure it is correctly inserted in the dedicated connector on both the Front board and the Relay board. Finally, if the issue persists, the protection fuses might be blown, requiring replacement by an authorized technician.
  • W
    williamsthomasAug 18, 2025
    What to do if the compressor does not work in my Irinox Refrigerator?
    • A
      Ana FloresAug 18, 2025
      If the compressor in your Irinox Refrigerator isn't working, start by checking the electrical line connection to ensure it's properly powered. If the power supply is not the issue, it could be due to several other reasons: blown auxiliary circuit protection fuses (requiring replacement by an authorized technician), intervention of internal Klixson for overload, a tripped circuit breaker switch, a pressure switch intervention for high pressure (ALP alarm), a missing relay board consent, or a broken remote switch. For these issues, intervention of a technician is required.
  • E
    Emily TapiaAug 22, 2025
    Why the cell fans do not turn in my irinox ICY Refrigerator?
    • S
      Sandra HayesAug 22, 2025
      If the cell fans in your Irinox Refrigerator aren't turning, first check the electrical line connection to ensure there is a power supply. If the power supply is fine, it might be due to a broken fan or a broken relay board, both requiring intervention of a technician for replacement.
  • S
    Sarah BakerAug 25, 2025
    What to do if the compressor works but it does not cool the cell in my irinox ICY?
    • J
      jennifernelsonAug 26, 2025
      If the compressor in your Irinox Refrigerator is running but not cooling the cell, it could be due to several reasons. There might be no refrigerant gas or a broken electrovalve, both requiring intervention of a technician. Alternatively, the condenser might be dirty ('Pulire batteria condensante'). Another possible cause is a broken liquid line electrovalve, which would require a technician to replace the electrovalve or coil.
  • C
    christine57Aug 28, 2025
    Why is the condensing fan not working on my irinox ICY?
    • H
      Harry HarrisAug 28, 2025
      If the condensing fan in your Irinox Refrigerator isn't working, first ensure it has a power supply by checking the electrical line connection. If the power supply is not the issue, it could be due to a broken pressure switch, a broken fan, a broken start condenser, or missing compressor remote switch consent. For all these causes, intervention of a technician is required to replace the device, fan, start condenser, or compressor remote switch.
  • O
    Olivia JonesSep 1, 2025
    How to fix the evaporator if it does not defrost in my irinox ICY?
    • A
      Ashley SharpSep 1, 2025
      If the evaporator in your Irinox Refrigerator isn't defrosting, the defrost cycle programming might be incorrect. Control defrost cycle programming.
  • J
    Joseph AdamsSep 4, 2025
    What to do if there is a door open alarm with door closed in my irinox ICY Refrigerator?
    • M
      michael53Sep 4, 2025
      If you're experiencing a door open alarm on your Irinox Refrigerator even when the door is closed, it's likely due to a faulty magnetic contact. Technician intervention is required.
  • B
    Brenda RileySep 7, 2025
    What to do if S2 cell probe is faulty in my irinox ICY?
    • M
      Michael CruzSep 7, 2025
      To address a faulty S2 cell probe in your Irinox Refrigerator, replace the S2 probe.
  • L
    Lisa NortonSep 10, 2025
    What to do if there is a total block with probes S1 and S2 faulty in my irinox ICY?
    • A
      Austin AdkinsSep 12, 2025
      If you are experiencing a total block with probes S1 and S2 faulty in your Irinox Refrigerator because probes S1 and S2 are broken, replace probes S1 and S2.

Summary

General Documentation

General Warnings and User Responsibilities

Outlines general warnings, user obligations, and intended use of the blast chiller.

Manufacturer Preamble and Directives

Details manufacturer declarations, conformity, and relevant directives for the equipment.

Transport and Handling Guidelines

Provides instructions for safely moving and handling the appliance.

Unpacking Instructions

Guides on how to unpack the blast chiller and check for damage.

Elementary Safety Standards

Lists fundamental safety rules to prevent injury and equipment damage.

Product Loading and Unloading Precautions

Advises on safe practices when loading and unloading products from the chiller.

Probe Usage Safety Precautions

Details safe handling and purpose of the temperature probe.

Periodic Personnel Training Requirements

Emphasizes the importance of regular training for machine operators and technicians.

Installation Procedures

Appliance Data Plate Information

Explains how to interpret the data plate for electrical and operational specifications.

Machine Positioning Guidelines

Covers recommendations for optimal and safe placement of the blast chiller.

Dimensional Data and Specifications

Provides detailed measurements and clearance requirements for the ICY S, M, and L models.

Room Temperature and Air Exchange Requirements

Specifies optimal ambient temperature and air circulation for unit performance.

Refrigeration Power Specifications

Details the refrigeration output and condensation power for different models.

Electrical Connection Instructions

Guides on proper electrical hookup, safety measures, and cable sizing.

Refrigeration Connection Details

Covers refrigerant connection specifics, including pressure switch calibration.

Condensation Drain System

Explains the function and location of the condensation collection tray.

Information for Installer

Provides crucial information for installers regarding inspection and customer notification.

Safety and Control Systems Overview

Describes the various safety features and control components of the blast chiller.

Machine Disposal Guidelines

Provides instructions for environmentally responsible disposal of the appliance.

R404 a Gas Safety Data Sheet

Details hazards, first aid, ecological information, disposal, and handling of R404a refrigerant.

Operation and Usage

General Use of Blast Chillers

Introduces the purpose and user-friendly design of the ICY series blast chillers.

Blast Chiller Cycle Descriptions

Explains the different blast chilling and freezing cycles available.

Control Panel Overview

Identifies the touch screen display and USB key interface.

Preliminary Operations and Pre-cooling

Covers initial setup and chamber pre-cooling before operating cycles.

Manual Mode Operation

Explains how to select and operate cycles in manual mode.

Automatic Mode Operation

Details how to operate cycles in automatic mode and cycle end procedures.

Defrost Cycle Management

Guides on selecting, starting, and managing the defrost cycle.

Data Printing and Recording Memory

Explains data download via USB and resetting the recording memory.

Stopping Modes and Usage Advice

Describes how to stop the machine and offers best practices for usage.

Product Loading and Pre-cooling

Details machine loading capacity and the pre-cooling procedure.

Core Probe and Food Preservation

Guides on core probe use and proper methods for food preservation.

Parameter Programming

Details how to access and configure cycle and user parameters.

Sanigen System Operation

Explains the function, usage, and operation of the Sanigen sanitising system.

Maintenance Procedures

Routine Maintenance Overview

Introduces routine maintenance tasks and safety standards.

Cleaning the Blast Chiller Cell

Provides instructions for daily and weekly cleaning of the machine's interior.

Washing the Evaporator

Step-by-step instructions for accessing and cleaning the evaporator.

Emptying Condensation Tray

Details how to empty and clean the condensation collection tray.

Cleaning the Condenser

Instructions for cleaning the condenser unit to ensure proper airflow.

Troubleshooting Common Issues

Lists common malfunctions, their causes, and possible solutions.

Extraordinary Maintenance Procedures

Information for specialised personnel on electrical and refrigeration part maintenance.

irinox ICY Series Specifications

General IconGeneral
CategoryRefrigerator
ModelICY Series
Installation TypeFreestanding
Defrost SystemAutomatic
CapacityVaries by model
Number of Doors1
