Roomba Anatomy
Cliff Sensor Openings
Edge-Cleaning
Side Brush
Main Cleaning Brushes
Vacuum Inlet
Brush Guard
Release Buttons
Contact Points for
Drive-on-Charger/ Charging
Wall Mount
Bin Release Button
Main Power Button
Battery Charger Socket
Battery Indicator
