Roomba 800 Series Owner’s Manual 15
EN
Debris Extractors
Extractor Caps
iRobot Roomba Anatomy
Cleaning Head
High-Capacity Sealed Bin
Extractor Frame
Extractor Frame Release Tabs
Sensor Port
Home Base
®
Contact Point
Removable
Caster Wheel
Home Base
®
Contact Point
Filter Door
Release Tab
Filter Door
Filter
