Irritrol Rain Dial Plus 12 User Manual

Set the Time
• Turn the Dial to Time .
• Press the +/- Buttons to set the current time (note AM or PM).
Set the Date
• Turn the Dial to Date.
• Press the +/- Buttons to change the year shown on the display.
• Press the Next Button; then press the +/- Buttons to change the month
(JAN, FEB, etc.) shown on the display.
• Press the Next Button; then press the +/- Buttons to change the date
.
• Press the Next Button to display the day of the week that automatically
corresponds to the date you have set.
1. Set the Function Switch to Set Program .
2. Set the Program Selector Switch to A, B or C program.
3. Turn the Dial as follows to select ONE of the watering day schedule options:
Daily Schedule
Turn the Dial to Sun (Sunday). Press the +/- Buttons for ON or OFF.
Repeat for each day of the week.
Note: If a Skip Days or Odd/Evn schedule is in use, it must be set to “OFF” before a
Daily schedule can be set. (See page 19, “What the Display Means.”)
Skip Days Schedule
Turn the Dial to Skip Days. “SKIP” is displayed. Press the +/- Buttons to
set the day interval between watering (01 – 15 days). For example, to
water every day, set 01. To water every third day, set 03, etc.
Getting Started
Automatic Operation, Step by Step
14
