Driving:
The IRUS UNITRAK is equipped with a variable drive system. By pushing the control lever (Fig. 2/7)
upwards, the machine is set in forward motion. The further the lever is moved, the faster the machine runs.
By moving the lever back, the machine slows down again. In the idling position, a catch can be felt on the
lever. The intensity of the latching can be adjusted (see maintenance work).
By pressing the control lever (Fig. 2/7) downward, the machine moves backwards in motion. The reverse
speed is also variable.
PTO:
The PTO is switched on by moving the lever (Fig. 1/5) forward. By moving the lever backward the PTO is
switched off.
Switching on:
01. Pull coupler lever (Fig. 1/7).
02. Move lever (Fig. 1/5) forward.
03. Let go the coupler lever (Fig. 1/7) slowly.
Switching off:
01. Pull coupler lever (Fig. 1/7).
02. Move lever (Fig. 1/5) backward.
03. Let go the coupler lever (Fig. 1/7) slowly.
Working:
01. Pull clutch lever (Figure 1/7).
02. Start the engine.
03. Engage the PTO.
04. Release clutch lever slowly.
05. Set the desired engine speed by operating the throttle accordingly.
06. Push the control lever slowly upward.
Pattern to be used when Pattern to be used when
working on flat even working on slopes.
ground.
