ISA FIJI - 11. Technical Specifications

20
USE AND MAINTENANCE MANUAL
EN
428000377137 FIJI
11. TECHNICAL SPECIFICATIONS
4 6 7 9 12 120 140
External
dimensions
Length mm
824 1214 1354 1659 2119 1214 1354
Depth mm
630 785
Height mm
1247
Weight (net)
Kg
67 99 110 135 172 110 135
4-6-7-9-12 120-140
ARRANGEMENT ICE CREAM CONTAINERS
+
Double reserve line
5 litres
360x165x120H
4.75 litres
260x157x170H
Model
