ISC Tronic - Table of Component Codes

Rev. 0128/01
TRONIC
SERVICE MANUAL
SYSTEMS
8
1.6) TABLE OF COMPONENT CODES
1
TRONIC 2K1 LOGIC BOARD
2
POWER CABLE
3
LP BALL VALVE
4
HP BALL VALVE
5
2200 mm BLUE CHARGING HOSE
6
2200 mm RED CHARGING HOSE
7
LP QUICK CONNECTOR
8
HP QUICK CONNECTOR
10
HP D80 GAUGE
11
LP D80 GAUGE
12
–1/10 bar PRESSURE SENSOR
13
DISTILLATOR
14
OIL SEPARATOR
15
DRYING FILTER
16
140 KPL COMPRESSOR
17
4,3 m3/h VACUUM PUMP
18
60 Kg LOAD CELL
20/21
OIL INJECTION/DRAIN CONTAINER
22
EXPANSION VALVE
25
500mm STRAIGHT+STRAIGHT HOSE
26
500 mm 90°+STRAIGHT HOSE
27
FAN CONDENSER
28
HP PRESSURE SWITCH
29
PROTECTION WIRE
30
500 mm 90°+STRAIGHT HOSE
31
CHECK VALVE M/F
32
CHECK VALVE
33
11,8 bar UNCONDENSABLES DISCHARGE VALVE
34
INTERNAL REFRIGERANT CONTAINER
39
500 mm STRAIGHT+STRAIGHT HOSE
40
PRINTER SET (OPTIONAL)
41
PAPER WIND KEY (OPTIONAL)
42
KPL DOUBLE POLE SWITCH
43
UPPER PANEL
45
FRONT PANEL
46
A200 REAR WHEEL
47
ROTATING FRONT WHEEL WITH BRAKE
48
SIDE POCKET
49
IDENTITY LABEL
50
KPL MANIFOLD
53
15 bar SAFETY VALVE
60
6 OUT 2K1 POWER BOARD
