6 FUNCTIONS OF THE OPERATION SCREENS CCW-R-2**B INSTRUCTION MANUAL
6-50
6.9 [Full Open Lock] Screen
To display the [Full Open Lock] screen, press the [Full Open] key on the [Main Menu] screen.
For mix weighers, select the section to be operated from the [Section Select] pop-up menu.
• Do not use the [Power] key during full open lock. Doing so may damage the device.
• DO NOT, UNDER ANY CIRCUMSTANCES, CLOSE THE HOPPERS WITH
HANDS OR TOOLS. Doing so may damage the drive unit.
• When the main power switch is turned off while the hoppers are open, or when
the hoppers remain open due to an electrical power failure, follow the
procedures described in “4.9 Handling Drive Unit” for the corrective action.
Fig.6-55 [Full Open Lock] Screen (Double Weigher)
To Next Page
