Measuringcentres–M
C
320,MC330,MC350&MC350H ‐ User’sManual 33


Days ina week andselected dates forholidaysdefinetimespotsforeach daily group inaperiodfortariff
switching.Datesforholidayshavepriorityoverdaysinaweek.

Whentherealtimeclockdateisequaltooneofadateofholidays,tariffisswitchedtoholiday,withinaperiod
ofactivedailygroupwithaselectedholiday.

Ifthereisnodateofholidaysthatisequaltotherealtimeclockdate,alldailygroupswiththeselectedcurrent
dayinaweekareactive.

Severaldailygroupscanbeactivesimultaneously,whichenablesmorethan4timespotsinoneday(combineof
dayprograms).Ifthetimespotisnotsetforacertainday,tariffT1ischosen.

Timeofarealtimeclockdefinesanactivetariffregardingcurrentlyactivedayprogram.AselectedtariffT1to
T4ofindividualtimespotisactivefromthetimeofthetimespottothefirstnexttimeoftheremainingtime
spots.

Theorderoftimespotsisnotimportant,exceptwhentwotimesareequal.Inthatcasethetimewithahigher
successivenumberhaspriority(ifseveraltimespotsareactive,timesofhighertimespotshavehighersuccessive
numbers),whilethetimespotwithalowernumberwillneverbeactive.
Ifcurrenttimeisbeforethefirsttimeofanytimespotofactivespots,thetimespotwiththelasttimeischosen.

Ifnotimespotofactiveprogramsisvalid,tariffT1ischosen.

TimeselectedtariffT1toT4orfixedselectedtariff(viacommunication)definesactivityofanenergycounter.
Countermeasuredquantity 
For each of four (4) countersdifferent measured quantity can be selected. User can select from a range of
predefinedoptionsreferringtomeasuredtotalenergyorenergyonsinglephase.Orcanevenselectitsown
optionbyselectingappropriatequantity,quadrant,absoluteorinversefunction.

Toenergycounteralsopulse/digitalinputcanbeattached.InthiscaseEnergycountercountspulsesfroman
outsidesource(water,gas,energy...meter).
Inputsandoutputs
MC3x0xcanbeequippedwithdifferentI/O.ForitstechnicalspecificationsseechapterTechnicaldataonpage
47.I/OareavailablealsooverProfibuscommunication–fordetailspleaselookintoAppendixC.

ForI/O1and2followingoptionsareavailable.

Module1‐Outputs:Therearetwodifferentoutputmodules.
‐ Pulseoutput(solidstate)
‐ Relayoutput(relay)

Module2‐Inputs:Therearetwodifferentinputmodules.
₋ Digitalinput
₋ Tariffinput

Tariffanddigitalinputcanbeorderedasadifferenthardwaretypeswithdifferentvoltagelevels.

AllmoduleshavedoubleinputoroutputandareinMiQensoftwarepresentedastwoseparatemodules.
