APPENDIXC:PROFIBUSPROTOCOL

6
6
 Measuringcentres
–
MC320,MC330,MC350&MC350H‐User’sManua
l

MODULE2:Power&Energy(Inputtelegram)
Profibus
byteindex
insidethe
telegram
Description
Modbus
addressstart
Modbus
addressend
DataType DataUnit
4 ActivePowerPhaseL1(P1) 32530 32531 Float W
8 ActivePowerPhaseL2(P2) 32532 32533 Float W
12 ActivePowerPhaseL3(P3) 32534 32535 Float W
16 ActivePowerTotal(Pt) 32536 32537 Float W
20 ReactivePowerPhaseL1(Q1) 32538 32539 Float var
24 ReactivePowerPhaseL2(Q2) 32540 32541 Float var
28 ReactivePowerPhaseL3(Q3) 32542 32543 Float var
32 ReactivePowerTotal(Qt) 32544 32545 Float var
36 ApparentPowerPhaseL1(S1) 32546 32547 Float VA
40 ApparentPowerPhaseL2(S2) 32548 32549 Float VA
44 ApparentPowerPhaseL3(S3) 32550 32551 Float VA
48 ApparentPowerTotal(St) 32552 32553 Float VA
52 CAP/INDP.F.Phase1(PF1) 32562 32563 Float 
56 CAP/INDP.F.Phase2(PF2) 32564 32565 Float 
60 CAP/INDP.F.Phase3(PF3) 32566 32567 Float 
64 CAP/INDP.F.Total(PFt) 32568 32569 Float 
68 EnergyCounter1 32604 32605 Float kWh
72 EnergyCounter2 32606 32607 Float kWh
76 EnergyCounter3 32608 32609 Float kWh
80 EnergyCounter4 32610 32611 Float kWh
84 AktivTariff 32622 32623 Float 

MODULE3:Inputs&Outputs(Inputtelegram)
Profibus
byteindex
insidethe
telegram
Description
Modbus
addressstart
Modbus
addressend
DataType DataUnit
4 AlarmStatusFlags(No.1…16) 30191 32531 T1 
6 AlarmStatusFlags(No.17…32) 30192 32533 T1 
8 I/O1Value 30193 32535 T17 
10 I/O2Value 30194 32537 T17 
12 I/O3Value 30195 32539 T17 
14 I/O4Value 30196 32541 T17 

