ISM SV-260 User Manual

12
6 AAB00400
Main case of control box 控制箱本體
1
7 BBH0150A
Releasable ties support 束帶-活動式
1
8 ADA00860
Releasable ties support frame 活動式束帶支撐架
1
9 AGA0410A
Screw +Spring washer +Washer 螺絲+彈簧華司+平華司
M4xS4x8x10L
20
10 CAA02219
Radiator resistor 水泥電阻
1
11 CMA00501
Main board ASM. SV-250 CTL 加工板組
1
12 AGA0306E
Self tapping screw 尖頭木螺絲 #3x6L
4
13 CMA00311
C02 display panel SV-500 顯示板加工板
1
14 ACA00560
Front cover 控制箱前蓋板
1
15 AGA0416D
Screw +Spring washer +Washer 螺絲+彈簧華司+平華司
M4xS4x9x16L
6
16 SNSC0005
Pedal sensor ASM. 速度基座組
1
17 CXA00241
Silicon rubber plate 模組矽膠片
1
18 CMB00151
PWR PCB ASM. SV-250 PWR 加工板組
1
19 AGA0308A
Screw +Spring washer +Washer 散熱片固定螺絲
M3xS3x6x8L
2
20 CKN00230
Power input line 電源輸入線 220V
1
21 AGA0416G
Screw +Spring washer +Washer 模組固定螺絲
M4xS4x8x16L
2
22 ADE00010
Cushion sheet 控制箱鎖合防震墊
6
23 CKN00250
CTL & PWR wiring connector 直流低壓電源線
1
24 ABD00090
Hexagon copper net 六角銅螺帽 M4x6L
6
25 CMB00161
FLT-T PCB ASM. 濾波板組
1
26 ACA00570
Control box lower cover
控制箱下蓋
1
