6.Pedal sensor neutral point setting mode
速度基座中立點設定模式:
1.Turn OFF the power
1 關掉電源.
2.Set pedal sensor in the neutral
point.
Press key, then turn ON the
power simultaneously and display
“OFSET”.
2.將速度基座置於中立點 ,
按住 鍵,同時打開電源.
出現 OFSET
3.Release key, display the
pedal sensor value that stored in
EEPROM.
3 放開 鍵 ,會出現儲存於
EEPROM 中速度基座的讀值 ;
4. Once press “UP” key, read the
pedal sensor again. If the value
between 1340~1790, press is “B”
key to store.
4.每按一次 UP 鍵則會重新讀取一
次速度基座 ,當出現的值介於
1340~1790 ,則按下 B 鍵儲存.
5.If always display “ERROR” that
means the pedal sensor neutral point
offset too much. The pedal sensor
mechanical neutral point must be
adjusted then repeat step 4.
5.若一直出現 ERROR 表示速度基
座中立點的機構位置偏離太多 ,必
須先調整速度基座中立點的機構
位置 ,再重復上述步驟 4 的動作.
BA
CD
A B C D
B
CD
A
A B C D
BA
B C D
A
CD
BA
B C D
A
CD
