ISM SV-260 User Manual

26
28 The curve slope of pedal s
troke vs. motor rotating
speed
踏板行程對應馬達速度曲線
0 〜 4
Bigger value means smaller curve slope
數值越大斜率越小
29 Accelerating slope
加速曲線
1 〜 8
Bigger value means slowly accelerating
數值越大加速越慢
30
The pedal stroke adjustment for motor start
rotating
馬達開始轉動的踏板行程調整
50 〜 90
(Pedal neutral reference point = 40, LD1 lighting)
(中立點參考值 = 40 , LD1 點亮 )
31 Pedal stroke adjusts for motor start accelerating
馬達開始加速的踏板行程調整
70 〜 110
32 Pedal stroke adjusts for foot lifter start acting
壓腳開始動作的踏板行程調整
20 〜 35
33 Pedal stroke adjusts for start thread trimming
切線開始動作的踏板行程調整
3 〜 30
34 Standing type pedal operating choice
立式作業選擇
OFF : Normal operation of speed pedal unit
速度基座正常操作
PK70 :
For JUKI standing operation PK70 type, the
speed is variable
配合 JUKI 立式作業 PK70 ,速度可變
PKSW : Standing pedal operation, the speed is
fixed (low speed & high speed)
立式作業 , 速度固定(低速&高速)
PK71 : Speed pedal unit normal control and with
foot lifting switch & thread trimming switch
function
速度基座正常操作,另外有壓腳開關及切線開
關的功能
35 Safety switch type
安全開關型式
N.O : Normal open switch
常開接點
N.C : Normal close switch
常閉接點
36 In auto test mode, motor running time adjustment
自動測試模式下,馬達運轉時間調整
2000 〜 8000 ms
37 In auto test mode, motor stopping time adjustment
自動測試模式下,馬達停止時間調整
2000 〜 8000 ms
38 Back tacking switch function
回針按鍵功能
BTSW : Control back tacking solenoid
控制回針線圈
N
DUP : Control back tacking solenoid when motor
runs, and as needle up switch when motor stops
運轉中控制回針線圈,靜止時提針至上停
