4
1-3 Front Panel
Refer to Figure 1 and the following numbered steps to familiarize yourself with the meter's front panel controls.
1. Digital Display — The digital display has a 3 1/2 digit LCD readout (maximum reading 1999) plus auto polarity,
decimal point,
< , DC,AC, and = .
2. Drop-Proof Wrist Strap — Prevents the instrument from slipping off the hand while in use.
3. Function Switch — Slide switch is used to select the desired range.
4. DC Zero Adj. Knob — Zero adjusts on DC current ranges.
5. AC/DC Slide Switch — Selects a.c. or d.c. current measurement.
6. Data Hold Switch — Holds display reading for all functions and ranges.
7. Trigger — Press the lever to open the current transformer jaws. When the pressure on the lever is released, the
jaws will close again.
8. Current transformer Jaws — Designed to pick up the current flowing through the conductor.
