Iso-Tech IDM101 - Capacitance, Continuity, Diode, Frequency

10
3.3.6 Capacitance
Range Resolution Accuracy Overload protection
4nF 1pF
±(1% + 40D)
600Vd.c. or
600V rms
40nF
400nF
4µF
±(1% + 4D)
40µF 10nF
±(1% + 4D) < 20µF
±(5% + 8D) > 20µF
10pF
100pF
1nF
Continuity testing:
Indication threshold : Approx. 40 Ω
Continuity indication : 2kHz tone
Input protection : 600Vor 600Vrms
Diode testing:
Measuring current : 0.6mA
Open circuit voltage : Approx. 3V
Input protection : 600V or 600Vrms
Frequency measurement:
Ranges : 100Hz, 1kHz, 10kHz, 100kHz, 10MHz
Resolution : 0.01Hz on 100Hz range
Accuracy : ±(0.1% + 4D)
Sensitivity : 40mVrms from 1Hz to 20kHz 400mVrms from 20kHz to 1MHz
Input protection : 600Vd.c. or 600Vrms
