Iso-Tech IDM101 - AC Current & Resistance

9
3.3.4 A.c. current (Aa.c.)
Range Resolution Accuracy
Voltage drop
4mA 1µA
±(1.5% + 5D)
40Hz to 1KHz
40mA 10µA
400mA 0.1mA
10A 10mA
±(2.5% + 5D)
40Hz to 1KHz
1V (max.)
800mV (max.)
Overload protection : mA jack: 1A/415V, 32 x 6.35mm quick-acting fuse.
A input terminal : 10A/415V, 32 x 6.35mm quick-acting fuse.
A.c. current conversion : Mean measured - r.m.s. value displayed.
3.3.5 Resistance (Ω)
Range Resolution Accuracy
Overload protection
400Ω 0.1Ω
±(0.7% + 3D)
600Vd.c. or
600V rms
4kΩ 1Ω
40kΩ 10Ω
400kΩ 100Ω
4MΩ 1kΩ ±(1.0% + 3D)
40MΩ 10kΩ ±(2.0% + 5D)
±(0.7% + 2D)
Open circuit voltage : 0.4V
