Iso-Tech IDM101 - AC Voltage & DC Current

8
3.3.2 A.c. voltage (Va.c.)
Range Resolution Accuracy
Over Voltage
protection
600Vd.c. or
600V rms
4V 1µV
±(1% + 5D)
50 to 60Hz
±(1.5% + 5D)
50 to 60Hz
40V 10µV
400V 100mV
600V 1V
Input impedance: 10M Ω in parallel with less than 100pF.
A.c. voltage conversion: Mean measured - r.m.s. value displayed.
3.3.3 D.c. current (Ad.c.)
Range Resolution
Accuracy
Voltage drop
4mA 1µA
±(0.8% + 2D)
40mA 10µA
400mA 0.1mA
10A 10mA
±(1.5% + 4D)
1V (max.)
800mV (max.)
