7
Dimensions (L x B x H(mm)) : 185 x 86 x 32,
with rubber holster: 200 x 98 x 52
Weight (inc. batteries) : 0.37kg
with rubber holster 0.6kg
Accessories : Rubber holster, test leads, batteries (fitted) and operating manual.
3.3 Electrical specification
Accuracy is given as ± (measurement error + display error) and applies at 23°C ± 5°C and less than 80% RH.
Measurement error (%) is given as a percentage of the current measurement.
Display error (D) is given in units equal to the smallest increment able to be shown on the display.
3.3.1 D.c. voltage (Vd.c.)
Range Resolution Accuracy
Over Voltage
protection
400mV 0.1µV
±(0.7% + 2D)
600Vd.c. or
600V rms
4V 1mV
40V 10mV
400V 100mV
600V 1V
±(0.5% + 2D)
Input impedance: 10MΩ.
