SERVICE INF
ORMATION 00 – 39
3.
Remove the element from the solution and rinse it
well with running water.
Water pressure must not exceed 274 kPa (2.8 kg/cm
2
/40Ps
i)
4.
Dry the element in a well ventilated area.
An electric fan will hasten drying.
NOTE:
Do not use compressed air or an open flame to dry
the element quickly. Damage to the element will
result. It will usually take two or three days for the
element to dry completely. Therefore, it is a good idea
to have a spare on hand to use in the interim.
LUBRI
CATING SYSTEM
Main Oil Filter (Cartridge Type Paper Element)
Replacement Procedure
1.
Loosen the used oil filter by turning it
counterclockwise with the filter wrench.
2.
Clean the oil filter fitting face.
This will allow the new oil filter to seat properly.
3. Apply a light coat of engine oil to the O-ring.
4. Turn in the new oil filter until the filter O-ring is fitted
against the sealing face.
5. Use the filter wrench to turn in the filter an additional 1
and 1/4 turns.
Filter Wrench : 5-8840-0200-0 (89mm/3.5in)
5-8840 0202-0 (106mm/4.2in)
5-8840-2209-0 (100.6mm/4.0in)
6.
Check the engine oil level and replenish to the
specified level if required.
Replenishment Engine Oil lit (Imp qt/US qt)
0.7 (
0.62/0.74)
7.
Start the engine and check for oil leakage from the
main oil filter.
0039-
1.tif
0039-2.tif
050LX001.tif
0039-4.tif
To Next Page
