TIGHTENING TORQUE SPECIFICATIONS
The tightening torque values given in the table below are applicable to the bolts unless otherwise
specified.
FLANGED HEAD BOLT N·m (kgf·m)
A bolt with an asterisk (*) is used for female screws of soft material such as cast iron.
M 6 × 1.0
M 8 × 1.25
M10 × 1.25
* M10 × 1.5
M12 × 1.25
* M12 × 1.75
M14 × 1.5
* M14 × 2.0
M16 × 1.5
* M16 × 2.0
004.6〜008.5 {00.5〜00.9}
010.5〜0196 {01.1〜02.0}
023.1〜038.5 {02.4〜03.9}
022.3〜037.2 {02.3〜03.8}
054.9〜082.3 {05.6〜08.4}
051.0〜076.5 {05.2〜07.8}
083.0〜125.0 {08.5〜12.7}
077.2〜116.0 {07.9〜11.8}
116.0〜173.0 {11.8〜17.7}
109.0〜164.0 {11.2〜16.7}
006.6〜012.2 {00.6〜01.2}
015.3〜028.4 {01.6〜02.9}
035.4〜058.9 {03.6〜06.1}
034.5〜057.5 {03.5〜05.8}
077.7〜117.0 {07.9〜11.9}
071.4〜107.0 {07.3〜10.9}
115.0〜172.0 {11.7〜17.6}
108.0〜162.0 {11.1〜16.6}
171.0〜257.0 {17.4〜26.2}
163.0〜244.0 {16.6〜24.9}
018.1〜033.6 {02.1〜03.4}
042.3〜070.5 {04.3〜07.2}
040.1〜066.9 {04.1〜06.8}
085.0〜128.0 {08.7〜13.0}
079.5〜119.0 {08.1〜12.2}
123.0〜185.0 {12.6〜18.9}
116.0〜173.0 {11.8〜17.7}
177.0〜265.0 {18.0〜27.1}
169.0〜253.0 {17.2〜25.8}
