Isuzu 4LE2 - Angular Nut and Bolt Tightening Method

GENERAL INFORMATION
9
1. Carefully wash the nuts and bolts to remove all oil
and grease.
2. Apply a coat of molybdenum disulfide grease to the
threads and setting faces of the nuts and bolts.
3. Tighten the nuts and bolts to the specified torque
(snug torque) with a torque wrench.
Snug torque
4. Draw a line [A-B] across the center of each bolt.
Center line
ANGULAR NUT AND BOLT TIGHTENING METHOD
Fig. 4
Fig. 5
Fig. 6
