SERVICE AND MAINTENANCE
- 5–2 -
Maintenance schedule: 4JB1, 4JB1-TC, 4JH1-TC engine Model specification
(I): Inspect then clean, repair or replace as necessary (A): Adjust (R): Replace (T): Tighten to specified torque (L): Lubricate
SERVICE INTERVAL x 1000 km
1 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
Use odometer
reading or months,
whichever occurs
first
x 100 mile
6 30 60 90 120 150 180 210 240 270 300 330 360 390 420 450 480 510 540 570 600
4JB
*Engine oil
- RRRRRRRRRRRRRRRRRRRRor every 3 months
4JH
*Engine oil
- -R-R-R-R-R-R-R-R-R-Ror every 6 months
*Engine oil filter - -R-R-R-R-R-R-R-R-R-Ror every 6 months
Fuel filter - - - - R - - - R - - - R - - - R - - - R or every 12 months
*Air cleaner element - - I-I-I-R-I-I-I-R-I-Ior every 24 months
Idling speed and acceleration - - - - I - - - I - - - I - - - I - - - I or every 12 months
Valve clearances - -------A-------A----or every 12 months
Fuel tank cap & fuel pipes for loose
connections or damage
--------I-------I---Ior every 24 months
4JB
Drive belt tension and damage
I-I-I-I-I-I-I-I-I-I-Ior every 6 months
4JH
Drive belt tension and damage
Every 7,500 km (4,500 miles): I or every 4.5 months
Engine coolant
Every 12 months: I
Every 24 months: R (when Isuzu recommended coolant is used)
*Damage to or looseness of the exhaust
pipe, exhaust brake (if equipped),
silencer, and their mountings
- - - - I - - - I - - - I - - - I - - - I or every 12 months
4JH
Exhaust pressure pipe
Every 12 months: I
Cooling system - - - - I - - - I - - - I - - - I - - - I or every 24 months
Damage to air intake ducts and hoses - -----I-----I-----I--or every 12 months
Engine operation condition - - I-I-I-I-I-I-I-I-I-Ior every 6 months
Clutch fluid - - I-I-I-R-I-I-I-R-I-Ior every 24 months
Clutch pedal travel and free play - IIIIIIIIIIIIIIIIIIIIor every 3 months
QKR-IE-14424805234ALL.indb5‒2QKR-IE-14424805234ALL.indb5‒2 2017/09/2713:34:512017/09/2713:34:51
