SERVICE AND MAINTENANCE
- 5–19 -
Free play
Allowance
Brake pedal free play and allowance
Free play: 4 to 7 mm (0.16 to 0.28 in)
NOTE
Stop the engine and depress the brake
pedal strongly about 10 times to set
the vacuum to 0 before measuring.
Allowance: 60 mm (2.36 in)
Note:
When depressed with force of 50 kg
(110 lbs).
NOTE
Let the engine run for at least 1minute
before taking measurement with the
engine running.
PERIODIC MAINTENANCE
Air cleaner
Use of clogged air cleaner element not
only causes a deterioration in the engine
output but also increased fuel
consumption and dark exhaust smoke.
The air cleaner element should be
serviced in the following manner.
NOTE
It is strongly advisable to use Isuzu
genuine air cleaner elements for
replacement.
