Isuzu Q Series User Manual

SERVICE AND MAINTENANCE
- 5–20 -
Element removal (Type 1)
1. Loosen the wing nut and remove the
outside cover.
2. Remove the wing nut retaining the
element and take out the element.
CAUTION
Handle the element carefully so as not
to damage it.
Element removal (Type 2)
1. Unhook the three hooks and remove
the cover.
2. Pull out the element.
CAUTION
Handle the element carefully so as not
to damage it.
