Isuzu Q Series User Manual

SERVICE AND MAINTENANCE
- 5–18 -
WARNING
The brake indicator light does not
indicate the parking brake function
or non-function. When applying the
parking brake, pull the parking
brake lever as far up as possible.
Do not continue to operate the
vehicle when the brake indicator
light is on. There may be serious
trouble in the brake system. Vehicle
operation under this condition is
extremely dangerous and can lead
to an accident.
Windshield washer solution level
Check that the washer tank is filled
sufficiently with solution. Also check the
operating condition of the windshield
washer.
Free play
Clutch pedal free play
Free play:
15 to 25 mm (0.59 to 0.98 in)
QKR-IE-14424805234ALL.indb5‒18QKR-IE-14424805234ALL.indb5‒18 2017/09/2713:34:532017/09/2713:34:53
