isweek M9803R - Input Terminals Explained

1. V Ω
Hz   Volt,Ohms,Diode,Frequency InputTerminal
Thisis thepositiveinput terminalforall functionexceptcurrent measurements.Connection ismadeto
usingtheRedtestlead.
2. COM Common Terminal
Thisisthenegative(ground)inputterminalforallmeasurementmodes.Connectionismadetousingthe
Blacktestlead.
3. mA MilliampInputTerminal
Thisisthepositiveinputterminalforcurrentmeasurement(ACor DC) up to 400 mA. Connection is made
tousingtheRedtestlead.
4. A 10 AmperesInputTerminal
Thisisthepositiveinputterminal for current measurement(ACorDC) up to 10A. Connection is made to
usingtheRedtestlead.
5. Function/RangeSelectorRotary Switch
Thisrotaryswitchselectsthefunction,andselectsthedesiredrange.
6. Function/RangeSelectorButtons
1-4
Thisbuttonsselectsthefunction,andselectsthedesiredrange.
