isweek M9803R - Basic Controls and Operation; Component Identification; Using the Rotary Switch

7.
TheLCDDisplay
TheLCDdisplayindicatesthemeasuredvalueofasignal,functionmode,andannunciator.
8. TheBattery Cover
9.
SupplyPowerInletwithFuse
WARNING
Toavoiduserforinjury and the multimeter for damage, the voltge valueofAC
power must be examined with same the power requirements of multimeter
beforeconnectpowercordtolivepowersourceandtheswitchisturnedon.
ThisswitchisusedtoturnACPoweronoroff.WhentheACPowerison,theDCPowerisautoturned
off.
10.
Thepowerswitch
11. RS232CSocket(tobuybyuseroptional)
UsingtheRotarySwitch
Turnthemultimeteronbyrotatingtherotaryswitchtoanyfunction.
1-5
