DCCurrent
Range resolution Accuracy(%rdg+digits)
4mA 1μA ±(0.8%rdg+5d)
40mA 10μA ±(0.8%rdg+5d)
400mA 100μA ±(0.8%rdg+5d)
10A 10mA ±(1.5%rdg+10d)
(20Afor30seconds)
InputProtection:F500mA/250VfuseformAinput;F15A/250VfuseforAinput
Burdenvoltage:600mVmax.formAinput;900mVmax.forAinput
ACCurrent
Range resolution Accuracy(%rdg+digits)
4mA 1μA ±(1.5%rdg+5d) 45Hzto400Hz
40mA 10μA ±(1.5%rdg+5d) 45Hzto400Hz
400mA 100μA ±(1.5%rdg+5d) 45Hzto400Hz
10A 10mA ±(2%rdg+10d) 45Hzto400Hz
(20Afor30seconds)
InputProtection:F500mA/250VfuseformAinput;F15A/250VfuseforAinput
Burdenvoltage:600mVmax.formAinput;900mVmax.forAinput
ACcoupledTrueRMSresponding
3-4
