SPECIFICATIONS
2
2- 2 V8.5e Rev 2.2.2002
~ Form feed adjust F2, F4, F8, tF, PF - selects
formfeed of 2, 4, 8 inches, Top of Form
sensing, and programable past top of form
respectively.
~ Bytes per scan b1, b2 - selects 216 and 264
bytes per scan respectively.
~ Grayscale levels per scan g1, g2, g3, g4 -
selects 8, 16, 32, and 64 levels of gray levels
per scan respectively.
# Grayscale media calibration table number
t1, t2.
Settings marked with (*) are used exclusively with bi-modal plotting.
Settings marked with (#) are used exclusively with grayscale plotting.
Settings marked with (~) are used with both bi-modal and grayscale
plotting.
Plot speeds Paper 1.0, 2.0, 3 .0, and 4.0 inches per second
in bimodal (black and white) plotting mode.
Film: 1.0 inch per second.
Grayscale: dependent upon the number of levels
of grayscale selected.
Condition detection Media out.
Top of form.
Head temperature.
24 volt error detection.
