4
OPERATION
4-9V8.5e Rev 2.2.2002
Scaling
The scaling function stretches or shrinks the plot over a 36-inch
length of plot with settings being S0 through SE. The default
setting is (S2). To determine if scaling is needed, plot a job of a
known length and measure it. Adjustments can be made to the
scaling in increments of + or - 1/16-inch over 36 inches of plot. S0
= no scale,
SE = +/- 14/16” over 36 inches of plot.
Note: Positive or negative scaling is selected through the Emulation
menu setting.
