EVENTUAL ANOMALY AND ITS REMEDIES
ANOMALY CAUSE REMEDY
The convector doesn’t start
Pilot doesn’t light
Verify/commute/replace:
- Irregular distance among injectors
- Selector knob on worng position
- Pilot injector dirty
Pilot doesn’t remain lighted
Verify/commute/replace:
- thermocouple failures
- dirty pilot injectorfa
Gas pressure not appropriate Regulate the proper pressure
Burned fuse Replace
High room temperature greater than settled valeu Regular the atmospheric thermostat on 7
Air in the gas tube Take out the air through the pipes
If the convector start (troubling functioning)
Dirty injectors Clean the injectors
Not proper Injectors for the gas used Use the proper injectors
gas Valve closed
Verify or replace
- Fault gas valve
If the timer doesn’t work
Electrical switch off Verify
Riders in the wrong position Regular the riders
Function selector in the wrong position Position on watch
Supply switch disconnected Reset and program the timer
The atmospheric thermostat doesn’t work
Thermostat knob doesn’t regulate
Regular the thermostat knob
-
On 1 to decrease
- On 7 to increase
Convector in wrong position Change the Position
Superior /inferior grill clogged Relase
Thermostat bulb out of his clip Set properly
Atmospheric thermostat breakdown Replace thermostat with gas valve group
Spark absence
Electrode group defected:
- failures
- earth
- wrong connection
Verify / Replace
Starting knob not much pressed
or wrongly rotated
Operate correctly on the knob
Piezoelectric ignitor failure Replace the gas valve group
