9) RICAMBI / SPARE PARTS / LISTE DES PIECES / ZEICHNUNGEN-ERSATZTEILE / RECAMBIOS
Ed. 05/13
DESCRIZIONE
CODICE/ITEM
DESCRIPTION
Q.TA'
Q.TY
ASSIEME CORPO RIDUTTORE A000014 ASSEMBLED GEARBOX BODY 1
GR. MOTORE TENSIONE ITA11 A000034 ITA11 TENSION MOTOR ASSEMBLED 1
GR. MOTORE TENSIONE ITA12 5000N A000035 ITA12 5000N - TENSION MOTOR ASSEMBLED 1
GR. CARTER ANTER. A000086 ASSEMBED FRONT COVER 1
GR. MOTORE TENSIONE ITA12 6000N A000131 ITA12 6000N - TENSION MOTOR ASSEMBLED 1
TUBO POLIUR.6X8 GRIGIO B100032 PIPE 6x8 (Lenght meters) 0,5 *
TAPPO 1/4" S2610 CAMOZZI B100296 GRUB 1/4" S2610 CAMOZZI 1
GOM.GIR ART RL31 8 1/4 (2L31011) B100310 SWING ELBOW RL31 8 1/4 1 *
GOM. GIR RL31 8 - 1/8 FOX B100311 SWING ELBOW RL31 8 - 1/8 2 *
IN. RAP. MASCHIO AN15A 1/4 B200309 FAST AIR MALE CONNECTION 1
VALVOLA PNEUMATICA B200347 PNEUM. VALVE 1 *
FASCIA TEFLON + BRONZ 1.5X6.1 MT B300020 GASKET 1.5X6.1 IN MTS 0,11
O-RING 2125 (D32) B300021 O-RING 2125 (D32) 1
O-RING 3300 (D85) B300022 O-RING 3300 (D85) 1
O-RING 2025/105 B300446 O-RING 2025/105 1
O-RING 4300 N B300451 O-RING 4300 N 2
CUSCINETTO A RULLI BK0810 INA B400001 ROLLER BEARING BK0810 1
CUSCIN. REGGISPINTA 7200BE 2RS B400002 BEARING 7200BE 2RS 1
CUSCINETTO A RULLI HK0808 INA B400003 ROLLER BEARING HK0808 2
CUSCINETTO 6001 2Z ERI B400004 BEARING 6001 2Z 2
CUSCINETTO A RULLI NK1616 B400005 ROLLER BEARING NK1616 1
CUSCINETTO 6001 2RS B400008 BEARING 6001 2RS 1
ANELLO IR 12x16x16 B400009 RING IR 12x16x16 1
ANELLO IR 12x16x20 B400339 RING IR 12x16x20 1
GABBIA ASSIALE AXK 1226 B400340 AXK1226 SKF 1
RALLA AS 1226 B400341 AS 1226 SKF 2
VITE TCEI M4X10 UNI5931 B500035 SCREW M4X10 1
VITE TCEI M4X8 UNI5931 B500037 SCREW M4X8 1
VITE TCEI UNC 10-24X1/2" B500039 SCREW UNC 10X1/2" 8 *
VITE TE M5X12 ECO-FIX ZINC.B. B500043 SCREW ECOFIX M5X12 ZINC 2
VITE TCEI M4X45 UNI5931L B500044 SCREW M4X45 3
VITE STEI M4X5 UNI5927 B500045 SCREW M4X5 2
VITE STEI M5X8 UNI5925 B500047 SCREW M5X8 2
VITE TPSCE M4X6 UNI5933 B500048 SCREW M4X6 3 *
DADO AUTOBL. ALTO M8 DIN982 5S B500053 SELFLOCK.NUT M8 H10 DIN982 1
VITE TCEI M3X8 UNI5931 B500068 SCREW TCEI M3X8 UNI5931 3
VITE STEI M8X6 UNI 5923L B500071 SCREW STEI M8X6 1
VITE TCEI UNC 1/4X5/8 ANSI B18.3 B500138 SCREW UNC 1/4X5/8 B18.3 5 *
RONDELLA SCHNORR DIAM.4 B500211 SCHNORR WASHER DIAM.4
2
SCREW STEI M4X5 UNI5923 B500379 SCREW STEI M4X5 UNI5923 1
VITE TCEI BASSA M4X30 DIN7984 B500386 SCREW M4X30 DIN7984 2
VITE TCEI UNC 1/4"X1/2" ANSI B18.3 B500407 SCREW UNC 1/4"X1/2" ANSI B18.3 1 *
VITE TBEI 10-24x5/8” B500456 SCREW 10-24x5/8” 1
ROND. SPESS. PS 10x16x0.5 B600011 WASHER PS 10x16x0.5 1
SEEGER PER ALBERI A10 U7435 R150 B600012 CIRCLIP A10 DIN471 1
SEEGER PER ALBERI H5 B600013 CIRCLIP H5 1 *
ROND. SPESS. PS 22x30x0,1 B600014 WASHER PS 22x30x0,1 VAR
