Key Name
Description
I-set(Function)
Current setting button, used to set the output current value of
power supply (set power supply List function/built-
in
waveform and PV curve function)
Recall(Save)
Callback button, used to recall a saved setting parameter/save
button, used to save a setting parameter.
Meter/(Local)
Meter button, used to switch the display between actual value
and setting value/switch to the local mode.
Enter/(Trigger)
Confirm button, used to confirm the setting numbers or
functions/trigger button
On/Off(Lock)
Ouput on/off button, used to control the output status of power
supply/kelock function button, u
sed to lock the front panel
buttons
Left and right direction button, used to adjust the location of the
cursor
Up and down direction button, used to select the items of the
menu or increase(
decrease) the output voltage and current
value
Confirm button
Return key
Dot
2.4 VFD Indicator Lamps Description
IT6500C series power supply VFD indicator lamps description as follows:
Flag
Function Description
Flag
Function Description
OFF
Power supply in off mode
Timer
none
CV
Power supply in CV mode
Sense
none
CC
Power supply in CC mode
Ext
none
*
Open the keylock function
Addr
When received command
successfully, the flag will
display 3 seconds.
Meter
“Meter” button in on mode
Rmt
Remote control mode
Shift
using composite function
Error
Error occur
Rear
Analog function begin to work
Prot
Protections for OV or OT
SRQ
Serial request query
Trig
waiting for triggering signal
OFF
Power supply in off mode
Timer
none
CW
Power supply in CP mode
-
-

ITech IT6513C Specifications

General

Brand	ITech
Model	IT6513C
Category	Power Supply
Language	English
